Wholesale Ricoh Fabric Printer

Digital textile/fabric printing machine with 12 pieces of Ricoh G5 print-heads

Short Description:

Ricoh G5 high-speed industrial-grade print nozzles can better meet the needs of industrial production.G5 Ricoh heads is high penetration so can print on carpet.
☆The application of negative pressure ink circuit control system and ink degassing system greatly improve the stability of inkjet.
☆Equipped with an automatic guide belt cleaning system to ensure continuous production and improve production efficiency.
☆Active rewinding/unwinding structure to ensure stable stretch and shrinkage of the fabric.
☆High penetration for printing carpet/blanket
☆Speed:130㎡/h(2pass)
☆Electric Device and mechanical parts imported from overseas to make our machine more solid and strong.
We purchase Ricoh heads from Ricoh directly while our competitors purchase Ricoh heads from agent of Rocoh. Our machine with Ricoh heads is best selling in China and quality is also the best.


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month

Product Detail

Product Tags

Digital Textile Printer For 12 Pieces Of Ricoh G5 Printing Head

Provide Acid,Pigment,Disperse,Reactive Solution

Specification



                                                 BYLG-G5-12

Printing width

2-30mm range is adjustable

Max. Printing width

1800mm/2700mm/3200mm

Max. Fabric width

1950mm/2750mm/3250mm

Production mode

130㎡/h(2pass)

Image type

JPEG/TIFF/BMP file format, RGB/CMYK color mode

Ink color

Ten colors optional:CMYK/CMYK LC LM Grey Red Orange Blue.

Types of ink

Reactive/Disperse/pigment/Acid/reducing ink

RIP Software

Neostampa/Wasatch/Texprint

Transfer medium

Continuous conveyor belt, automatic winding

Head cleaning

Auto head cleaning & auto scraping device

Power

power≦25KW ,extra dryer 10KW(optional)

Power supply

380vac plus or mius 10%,three phase five wire.

Compressed air

Air flow ≥ 0.3m3/min, air pressure ≥ 6KG

working environment

Temperature 18-28 degrees, humidity 50%-70%

Size

4100(L)*4900(W)*1520MM(H)(width 1900mm),

4900(L)*2485(W)*1520MM(H)(width 2700mm)

5400(L)*2485(W)*1520MM(H)(width 3200mm)

Weight

2800KGS(DRYER 750kg width1800mm) 3200KGS(DRYER 900kg width 2700mm)4300KGS(DRYER width 3200mm 1050kg)

Why choose Digital Textile printer

Digital textile printing machines offer numerous benefits over traditional methods, including faster turnaround times, greater design flexibility, lower production costs, and reduced waste. They also enable printing on a wide range of fabrics and allow for small batch production, making them ideal for customization and on-demand production.

Why choose Boyin's digital printing machine

Boyin's digital textile printing machines are a great choice because of advanced technology, high precision, and reliability. We offer high-quality printing with vibrant colors and sharp details, and  user-friendly software makes it easy to design and print customized fabrics with excellent customer service and technical support.

Product Description

parts and software

All our machine has passed strict testing, and comply with international standards and industry standards.We also have obtained a variety of new-use patents and invention patents. Our machine are sold to more than 20 countries and regions including India, Pakistan, Russia, Turkey, Vietnam, Bangladesh, Egypt, Syria, South Korea, Portugal, and the United States. We have offices or agents at home and abroad.
