Double Sided Synchronous Digital Textile printing machine

Short Description:

★BYDI’s newly developed double-sided synchronous printing machine type,If you want to customize double-sided with the same image the same color, the same image different color, the different image different colour，can’t miss this machine！！！！！ Boyin 2024 new machine S10

★8 pcs Ricoh G6print-heads

★3 kinds production models

★3 kinds capcity

★5 kinds inks can be choosed

★8 colours can be applied in

Send email to us

Product Detail

Product Tags

Double Sided Synchronous Digital Textile Printer With 8 Pieces Of Ricoh G6 Printing Head

Provide Acid,Pigment,Disperse,Reactive Solution

Specification

BYLG-S10-G6-8
Printing width	1600mm
Printing Modles	the same image the same colour；the same image different colour ；the different image different colour
Max. Fabric thickness	≤3mm
Production mode	50㎡/h(2pass)；40㎡/h(3pass)；20㎡/h(4pass)
Image type	JPEG/TIFF/BMP file format, RGB/CMYK color mode
Ink color	Ten colors optional:CMYK/CMYK LC LM Grey Red Orange Blue.
Types of ink	Reactive/Disperse/pigment/Acid/reducing ink
RIP Software	Neostampa/Wasatch/Texprint
Transfer medium	Continuous conveyor belt, automatic winding
Head cleaning	Auto head cleaning & auto scraping device
Power	power≦25KW ，extra dryer 10KW(optional)
Power supply	380vac plus or mius 10%,three phase five wire.
Compressed air	Air flow ≥ 0.3m3/min, air pressure ≥ 6KG
working environment	Temperature 18-28 degrees, humidity 50%-70%
Machine Size	3800(L)1738(W)1977MM(H)
Package Size	4000(L)1768(W)2270MM(H)

Why choose Digital Textile printer

Digital textile printing machines offer numerous benefits over traditional methods, including faster turnaround times, greater design flexibility, lower production costs, and reduced waste. They also enable printing on a wide range of fabrics and allow for small batch production, making them ideal for customization and on-demand production.

Get Started

Why choose Boyin's digital printing machine

Boyin's digital textile printing machines are a great choice because of advanced technology, high precision, and reliability. We offer high-quality printing with vibrant colors and sharp details, and user-friendly software makes it easy to design and print customized fabrics with excellent customer service and technical support.

Get Started

Product Description

All our machine has passed strict testing, and comply with international standards and industry standards.We also have obtained a variety of new-use patents and invention patents. Our machine are sold to more than 20 countries and regions including India, Pakistan, Russia, Turkey, Vietnam, Bangladesh, Egypt, Syria, South Korea, Portugal, and the United States. We have offices or agents at home and abroad.
