UV Digital Printing Machine With 16 Pcs Of G6 Ricoh Print Head

Short Description:

*Ricoh G6 high-speed industrial-grade print nozzles is high accuracy.

*Using magnetic levitation linear motor so printing accuracy is high.
*The application of negative pressure ink circuit control system and ink degassing system greatly improve stability of inkjet.
*Equipped with an automatic cleaning system for the guide belt to ensure continuous production and improve production efficiency.
*Active rewinding/unwinding structure to ensure stable stretch and shrinkage of the fabric.

Send email to us

Product Detail

Product Tags

UV Digital Textile Printer

Provide UV Solution

Product Details

UV
Printer head	Ricoh G6 Print head
Print width	2-30mm range is adjustable
Max. Print width	1900mm/2700mm/3200mm
Max. Fabric width	1950mm/2750mm/3250mm
Production mode	310㎡/h(2pass)
Image type	JPEG/TIFF/BMP file format, RGB/CMYK color mode
Ink color	Ten colors optional:CMYK/CMYK LC LM Grey Red Orange Blue.
Types of ink	Reactive/Disperse/pigment/Acid/reducing ink
RIP Software	Neostampa/Wasatch/Texprint
Transfer medium	Continuous conveyor belt, automatic winding
Head cleaning	Auto head cleaning & auto scraping device
Power	power≦25KW extra dryer 10KW(optional)
Power supply	380vac plus or mius 10%,three phase five wire.
Compressed air	Air flow ≥ 0.3m3/min, air pressure ≥ 6KG
working environment	Temperature 18-28 degrees, humidity 50%-70%
Size	4200(L)2510(W)2265MM(H)(Width 1800mm） 4980(L)2510(W)2265MM(H)(Width 2700mm） 5480(L)2510(W)2265MM(H)(Width 3200mm）
Weight	3500KGS(DRYER 750kgWidth 1800mm) 3900KGS(DRYER 900kg Width 2700mm) 4500KGS(DRYER Width 3200mm 1050kg)

Why choose Digital Textile printer

Digital textile printing machines offer numerous benefits over traditional methods, including faster turnaround times, greater design flexibility, lower production costs, and reduced waste. They also enable printing on a wide range of fabrics and allow for small batch production, making them ideal for customization and on-demand production.

Get Started

Why choose Boyin's digital printing machine

Boyin's digital textile printing machines are a great choice because of advanced technology, high precision, and reliability. We offer high-quality printing with vibrant colors and sharp details, and user-friendly software makes it easy to design and print customized fabrics with excellent customer service and technical support.

Get Started

Video

Why Choose Us
1: 8000 square meters factory.
2: Powerful R&D team,responsible big after-sales service.
3: Our machine is very famous and earn a good reputation in china.
4: No.1 industry for pigment and disperse of fabric digital printer in china.

About Us

We a leading manufacturer of digital textile printers. With years of experience and a commitment to quality, we specialize in providing innovative solutions for textile printing. Our state-of-the-art technology ensures precision, reliability, and cost-effectiveness, making us the preferred choice for businesses of all sizes. Discover the power of digital textile printing with Boyin today.

Our Services

We provide comprehensive solutions for all your printing needs. Our services include technical support, training, and maintenance, ensuring that your business runs smoothly and efficiently. With our commitment to excellence, we help you achieve your printing goals with ease and confidence. Experience unmatched quality and service with Boyin today.
